Electric propulsion systems for satellites

Roundup

Electric propulsion (EP) is an in-orbit technology that can add a new dimension to the way that satellites operate in space. Unlike traditional chemical propulsion systems, which rely on the combustion of fuel to generate thrust, electric propulsion uses electrically charged particles, resulting in an efficient and precise form of propulsion.

Electric propulsion-based thrusters have a variety of potential advantages over traditional chemical propulsion, including greater fuel efficiency, longer mission lifetimes, and greater maneuverability.

One of the most common types of EP used in satellites is ion thrusters. These thrusters work by ionizing a gas, typically xenon, and accelerating the resulting charged particles out of a nozzle to create thrust.

Ion thrusters’ ensure efficiency due to high exhaust velocity, which is typically significantly higher than that of traditional chemical thrusters. This enables spacecraft to achieve greater speeds and travel further distances, making it a very suitable option for long-duration missions.

Another form of electric propulsion is Hall thrusters. These work similarly to ion thrusters but use a magnetic field to accelerate the charged particles instead of an electric field. Hall thrusters are known for their high thrust efficiency and ability to operate at a higher power level than ion thrusters. They are often used in applications that require high-thrust, such as orbit raising and station-keeping.

electric propulsion thrusters - image showing two cubesats orbiting earth

Electric propulsion systems can usually operate for extended periods without the need for refueling, allowing for longer mission lifetimes. In addition, EP systems are highly controllable, allowing for precise adjustments to satellite trajectories and orientation. This precise control is particularly useful for maintaining a satellite’s position and avoiding collisions with other objects in space – an increasingly important application as the volume of space traffic grows.

Despite the many advantages of EP, there are some drawbacks to consider. Electric propulsion systems typically have lower maximum thrust levels than traditional chemical thrusters, which can make them less suitable for certain applications such as initial orbit insertion. Electric propulsion systems also require a significant amount of power, which can be challenging to provide on smaller spacecraft.

Overall, EP thrusters provide an efficient and precise form of propulsion that is becoming increasingly popular in the satellite industry. As technology advances, it is likely that we will see even more advanced electric propulsion systems developed, allowing for even greater efficiency and versatility in satellite operations.


Electric propulsion systems on the global marketplace

In this section you can find details of electric propulsion systems and satellite thrusters from manufacturers around the world. You can click on any of the links below to find out more.

From the product pages you can submit free requests for further information, quotes, documents, or whatever else you might need for your procurement or trade study processes.

Alternatively, to quickly send out a free and no-obligation request for quote or proposal to all of these companies, click here and share your requirements with us.


While the required power to operate the ENPULSION NANO starts at around 10 W, at higher thrust levels one can choose between high thrust and high specific impulse operation. The ENPULSION NANO can operate at at an Isp range of 2,000 to 6,000 s.

While the required power to operate the ENPULSION NANO R³ starts at around 8 W, at higher power levels one can choose between high thrust and high specific impulse operation. The ENPULSION NANO R³ can operate at an Isp range of 2,000 to 6,000 s.

enpulsion-enpulsion-nano-ir3

The ENPULSION Nano AR³ uses differential emission throttling within the proprietary crown ion emitter to control actively the emitted ion beam and, therefore, thrust.

Building on the heritage of the ENPULSION NANO, ENPULSION has developed a scaled version of the technology to target small and medium size spacecrafts. The ENPULSION MICRO R³ is engineered in a modular approach, with units clustering easily together to form building blocks.

The Exotrail spaceware™ Nano L Thruster is a 60W-class system designed for satellite platforms ranging between 10 to 80kg. It utilizes Xenon as a propellant and has a maximum total impulse of 5.4 kNs. The thruster's tilt is adjustable for CubeSats between 6U and 20U. Its Thruster Control Unit (TCU) can be mounted separately from the thruster body.

The Exotrail spaceware™ Nano L Thruster is a 60W-class system designed for satellite platforms ranging between 10 to 80kg. It utilizes Xenon as a propellant and has a maximum total impulse of 5.4 kNs. The thruster's tilt is adjustable for CubeSats between 6U and 20U. Its Thruster Control Unit (TCU) can be mounted separately from the thruster body.

The Exotrail spaceware™ Micro XL Thruster is a 150W-class system developed for microsatellites. It offers high thrust and huge maneuver capabilities for microsatellites. The thruster utilizes Xenon as a propellant and has a maximum total impulse of 52 kNs. Its tilt is adjustable towards the center of mass to a wide extent with low thermal influence on the platform.

The Exotrail spaceware™ Micro XL Thruster is a 150W-class system developed for microsatellites. It offers high thrust and huge maneuver capabilities for microsatellites. The thruster utilizes Xenon as a propellant and has a maximum total impulse of 52 kNs. Its tilt is adjustable towards the center of mass to a wide extent with low thermal influence on the platform.

The Exotrail spaceware™ Micro Cluster² XL Thruster is developed with cluster configurations for microsatellite platforms. It utilizes Xenon as a propellant and has a maximum total impulse of 115 kNs. The cluster configurations provide flexibility to meet the high thrust and lifetime demands of missions as per the customer requirements. It also opens up the door to AOCS capabilities and allows optimal performance in all the throttling scales.

The Exotrail spaceware™ Micro Cluster² XL Thruster is developed with cluster configurations for microsatellite platforms. It utilizes Xenon as a propellant and has a maximum total impulse of 115 kNs. The cluster configurations provide flexibility to meet the high thrust and lifetime demands of missions as per the customer requirements. It also opens up the door to AOCS capabilities and allows optimal performance in all the throttling scales.

The Exotrail spaceware™ Mini M Thruster is a 400W-class system designed for small satellite platforms. Its tilt is adjustable towards the center of mass to a wide extent with low thermal influence on the platform. The thruster consists of multi-propellant capabilities, using either Xenon, Krypton, or Iodine. It is mainly developed for NewSpace companies targeting small satellite constellations.

A launch-safe and cost-effective electrothermal propulsion system that uses water as propellant. The Comet produces 17 mN thrust with a specific impulse of 175s. It is approved for flight on multiple launch vehicles and features a flexible interface suitable for use with a wide range of spacecraft sizes.

The Steam TunaCan Thruster is a water-powered, electrothermal propulsion system specifically designed for CubeSats. The tailored shape factor has been designed to allow its installation in the “tunacan” volume located outside the main CubeSat structure, available in most of the CubeSats deployers.

The Steam Thruster One is a flight-proven, water-powered, electrothermal propulsion system specifically designed for CubeSats and Small Satellites. The system features a tailored design and manufacturing approach that allows for customization, to meet a wide range of different mission requirements. The specifications are given for a representative 2U propulsion unit.

The Pale Blue Water Ion Thruster is a low pressure, low power propulsion unit with a scalable water tank and a redundant flow control system. It features hollow cathodes and electrodes for an enhanced lifetime of the overall system. It features both UART and RS422 command interfaces. The thruster is modularized and it is also possible to enhance the overall system by clustering thruster units and scaling the propellant tank as needed.

The Pale Blue Water Resistojet Thruster is a low pressure (<60 kPa) propulsion system with a scalable water tank and a redundant flow control system with a fail-safe valve. The thruster unit is modular and it is possible to expand the overall system by clustering multiple units and scaling the propellant tank as needed. The limits of such clustering or scaling are determined by the mass, volume, or power of a spacecraft.

The Rafael Ltd R-800 thruster is a Hall-effect thruster (HET) suitable for low to medium mass satellite platforms (<1,000 kg). With Xenon as propellant, the system features a permanent magnet and center-mounted low current heaterless hallow cathode configuration resulting in a low volume and mass footprint and low power consumption. The gas distributor of the thruster also serves as the anode.

The Rafael Ltd Israeli Hall-Effect Thruster IHET-300 is a hall effect thruster operating on Xenon as propellant suitable for small and microsatellite. The IHET-300 thruster is part of the Electric Propulsion System (EPS) on Venus program. The thruster’s operational anode power may utilize the instantaneous available power from the satellite.

The Rafael Ltd R-200 EPS is an Electric Propulsion System consisting of R-200 Hall Effect thruster (HET) with Xenon and Krypton as propellants. The system also includes power processing unit and propellant management assembly. The space-qualified R-200 EPS is an improved version of the Rafael’s R-400 EPS. The system is fully space-qualified.

The Rafael Ltd R-200 thruster is a Hall Effect Thruster (HET) suitable for low to medium mass satellite platform with Xenon as propellant. The non-conventional configuration of having an elongated discharge channel and co-axial anodes helps overcome the low mass utilization efficiency issues. The system is fully space-qualified and has undergone vibration, shock and full lifetime tests.

The Rafael Ltd R-800 EPS is a Eelctric Propulsion system consisting of two R-800 Thruster, PPU, Propellant Tank, Propellant Feed System.The Rafael Ltd R-800 thruster is a Hall-effect thruster (HET) suitable for low to medium mass satellite platforms (<1,000 kg). With Xenon as propellant, the system features a permanent magnet and center-mounted low current heaterless hallow cathode configuration.

REGULUS

DATASHEET

T4i’s Regulus is designed based on Magnetically Enhanced Plasma Thruster (MEPT) technology. The highly modulable plug&play thruster uses iodine as a propellant, and produces a specific impulse of up to 650 s with a nominal input power of 50 W.

The IENAI SPACE Adaptable THruster based on Electrospray for NAnosatellites (ATHENA) is a fully customizable, on-board electric propulsion system, that can be tailored to spacecraft platform constraints, and specific mission requirements.

The ThrustMe NPT30-I2 1U is a miniaturized, propulsion system based on gridded ion thruster technology. The launch-qualified thruster has modular design, passive thermal management and intelligent operation control. It uses safe, non-pressurized solid iodine as propellant.

The ThrustMe NPT30-I2 1.5U is a modular, stand-alone propulsion unit based on gridded ion thruster technology and features a patented, pipeless design. The system utilizes solid iodine fuel and incorporates embedded intelligent controls and passive thermal management.

The ThrustMe I2T5 is a non-pressurized, cold gas propulsion system operating with Iodine as propellant. The I2T5 stand-alone system includes the propellant storage, the flow control, the PPU, as well as thermal management and intelligent operation all embedded into a 0.5U form factor.

morpheus-space-nano-feep morpheus-space-multi-feep

The Nova product-line is the baseline propulsion system used in the ORB-class satellite platforms. It is specifically built to capitalize on usage of the "tuna-can" volume made available for nanosatellites, minimising impact on volume consumed within the platform. It uses a low melting point, liquid metal propellant with no pressurized tanks or moving parts.

The Kilonova is an upgradable variant of OrbAstro's Nova propulsion system, built for compatibility with CubeSat platforms and suitable for larger ORB-class and Guardian-class satellite platforms. It is designed to work with the "tuna-can" volume and uses a liquid metal propellant with a low melting point and no pressurized tanks or moving parts.

The Supernova is an upgradable model of OrbAstro's Nova. It uses a low melting point liquid metal propellant, with no pressurized tanks or moving parts, and built for compatibility with CubeSats and suitable for larger Guardian-class and ORB-class satellite platforms.

A miniaturized centerline-cathode Hall Effect Thruster (HET) designed to offer a high-performance, high-delta-V, launch-vehicle-compliant propulsion solution for CubeSats. The system uses magnetic fields to focus and accelerate plasma in order to generate thrust and the system operates on a flexible range of inert gases and storable propellants, without combustion.

The Tiled Ionic Liquid Electrospray (TILE) 2 is a small satellite thruster provided in a 0.5U form factor. It operates at a typical total impulse of 21 Ns and delivers a maximum axial thrust of 0.04 mN. The ionic-liquid propelled thrusters have an operating temperature range of 10 to 50 °C. The maximum power drawn is 4 W.

The Tiled Ionic Liquid Electrospray (TILE) 3 system is a scalable, modular ion thruster with no heavy tanks, toxic propellants, external cathodes, or ionization chambers. It has a volume of 1U, a wet mass of 2 kg, and is produced using commercial MEMS manufacturing processes.

The plug&play Hydros-C thruster uses water propulsion technology and has a specific impulse of > 310s. The orbit-averaged thrust is 2.2 mN with a thrust efficiency of 0.13 MN/W. With 0.5 kg water capacity, the thruster has a lifetime of 3 years in LEO and capable of delivering > 1.2 N thrust.

The HYDROS-M is designed to fit inside a 15″ separation ring and sized for micro-satellites. The system uses water as propellant, with a capacity of 6.0 kg, the thruster has a specific impulse of > 310s, orbit-averaged thrust of 6.8 mN, and a thrust efficiency of 0.16 mN/W.

Bellatrix Aerospace has developed and patented Microwave Electro-thermal Thrusters (MET), an advanced form of electric propulsion system for satellites. The technology has the ability to work effectively with several propellants such as argon, xenon, nitrogen, ammonia and water vapour.

Bellatrix's Hall Effect Thruster or Stationary Plasma Thruster (SPT) is an ion propulsion system that generates thrust by trapping electrons in a magnetic field and then using them to ionize propellant and efficiently accelerate the ions to produce thrust. Forms of Bellatrix SPT, with 40mN and 90mN thrust output, are under development.

Magnetoplasmadynamic Thruster (MPDT's) or Lorentz Force Accelerators (LFA) are an advanced form of electric propulsion system, capable of generating high thrust (~200N) with very high specific impulses (>20,000 seconds). While currently unsuitable for space applications (due to requiring power in the range of 50-200 MW) Bellatrix has been performing R&D on MPDTs since June 2013.

Maxwell is a plasma propulsion system designed for small satellites. The system encompasses a proprietary RF thruster, xenon propellant tank, power electronics and flight software in a compact package suitable for restricted volumes.

ARM-O is a CubeSat propulsion system designed for orbital control, station-keeping, and collision avoidance, utilizing a water-based propellant. ARM-O is the simplest variant of the Aurora Resistojet Module product family and generates unidirectional thrust. 1-4 thrusters can be included based on requirements.

The water-based propulsion system has a compact and lightweight design with various tank sizes, that are customizable for mission requirements. The thruster enables full 3-axis attitude control for target satellites 1–3U, 6U, and 12U, based on the tank variants.

One of the smallest available systems capable of controlling all directions of satellite movement. The thruster offers a customizable tank and module size with 4 or 6 degrees of freedom (ARM-AO vs ARM-6) and integrated attitude determination. The thruster technology is safe, green and has low power consumption.

The ARM-E can be attached to typically any external propellant tank. The thruster is suitable for satellites that require accurate movement functionality, such as attitude control, more precise control, or greater additional thrust. The variants include ARM-AE, ARM-AOE, ARM-OE, and ARM-6E.

The BHT-200 is Busek’s flagship matured propulsion system, with a proven flight heritage and currently operating on-orbit. The thruster features a patented design covered under “Tandem Hall Field Plasma Accelerator”. Iodine-compatible versions of the thruster have also been delivered for the MFSC iSat mission.

The TRL-6 matured Hall Effect Thruster (HET) technology features cathodes, PPUs, and a feed system of proven flight heritage. The thruster uses xenon and iodine as propellants. A hybrid variant (BHT-600i) using iodine as anode and xenon as cathode, has also been demonstrated.

A 2 kW-class Hall Effect Thruster (HET) designed for use with xenon, iodine and krypton as propellants. The BHT1500 features an innovative center-mounted cathode that reduces performance degradation and delivers a thrust of 103 mN at a power of 1800 W power, and a specific impulse of 1,820s.

The BHT-8000 is a mature HET operating on xenon and krypton as propellants, with a center-mounted cathode. The 8 kW (nominal) thruster features precisely designed magnetic field distribution for high total impulse and efficiency. Available configurations are circular, clustered, racetrack, and nested.

An ion thruster that utilizes an inductively coupled plasma (ICP) source. The system features a BRFC-1 RF Cathode and has an ion beam current of 2.7 mA. The unit has been designed to work with xenon propellant but is compatible with a range of other fuels.

The gridded ion thruster operates at 56-80 W input power and uses an inductively-coupled plasma (ICP) discharge. The thruster uses solid iodine as propellant, eliminating the need for high-pressure tanks, and an innovative thruster gimbal system enables attitude control.

A 460 W ion thruster featuring an inductively coupled plasma (ICP) source. The system is designed to work with xenon propellant but is compatible with a variety of other fuels. It includes a BRFC-1 RF Cathode and can produce a thrust of 11.0 mN.

With proven flight heritage, the rugged, small, safe, and precise micro-pulsed plasma thruster is suitable for CubeSat and microsatellite propulsion and attitude control. The BmP-220 uses non-toxic solid propellant teflon, featuring long storage life with no pressure tanks and no moving parts.

Busek’s micro-Pulsed Plasma Thrusters (μPPTs) have been in development since 2002 based upon technology originally developed at AFRL. These simple units feature no moving parts and non-toxic teflon propellant.

The Busek 3-axis μPPTs, or MPACS (Micro Propulsion Attitude Control System), are thruster units that produce precise, pulsed impulse bits (80μN-s), utilizing solid propellant. The systems feature no pressurized containers, no moving parts, and low power consumption (< 10W). Direct flight heritage was first achieved on the 2007 FalconSat-3 mission.

A multiplexed array of 9 μPPTs was constructed and delivered to the Air Force Institute of Technology as a lab- model test unit. This unit featured flight heritage μPPTs technology, increased the amount of total impulse of the MPACS unit while decreasing required power and digital electronics.

An integrated primary and attitude control system, with a specific impulse of 150s for the primary and 80s for each ACS thruster. The thruster can deliver 0.5 mN of thrust for each of 8 ACS thrusters and has full 6 degrees of freedom control for a Cubesat. The MRJ features a non-toxic, safe propellant.

The CubeSat High Impulse Propulsion System (CHIPS) adopts patended resistojet technology. The thruster is compact, with a size of 0.6 U and 0.3 U with and without Attitude Control System. The ACS allows a full 6 degrees of freedom. The thruster has warm/cold gas operational modes.

The CU Aerospace (CUA) Fiber-fed Pulsed Plasma Thruster (FPPT) system is a pulsed plasma thruster that uses PTFE fiber as propellant. The FPPT starts immediately without warmup and mechanically feeds PTFE propellant fiber from a non-rotating spool through the anode where it is subjected to a pulsed discharge and electromagnetically accelerated to provide thrust.

The CUA Monofilament Vaporization Propulsion (MVP) system is an electrothermal thruster that uses a space-rated plastic as propellant. The MVP draws from 3D printing technology to feed propellant. A preheat is required before firing (~3 minutes), but once warmed the “ready” state is maintained with minimal power draw and thermal loading.

The HT 100 Hall Effect Thruster (HET) is one of the smallest and lowest power HETs ever developed in Europe. Based on permanent magnets, the HT 100 HET is designed to perform orbit control tasks on micro-satellites and AOCS tasks on mini-satellites, and all components are ITAR-free.

A Hall Effect Thruster (HET) designed to be operated at a nominal discharge power of 20kW. The system has been designed to offer a favourable combination of performance, reliability, and lifetime. To improve the thruster-cathode coupling, HT20k features an internally mounted hollow cathode, the SITAEL HC60, located inside the inner pole of the magnetic circuit.

The HT 400 Hall Effect Thruster (HET) has been designed to perform orbit and attitude control tasks on micro- and mini-satellites. The system's function is based on permanent magnets and it is designed to be installed onboard telecommunication and Earth Observation (EO) platforms.

The HT 5k Hall Effect Thruster (HET) has been designed to meet the requirements of modern communication and navigation satellites, performing propellant-saving LEO-GEO/LEO-MEO transfers, as well as station-keeping tasks on large geostationary platforms.

Designed for use as part of the propulsion system for satellites with onboard power larger than 300 W. The structure of ST25 includes a combination of solenoids and permanent magnets to minimize the electric power needed to create the magnet field in the acceleration channel.

The SETS Hall Effect Thruster (HET) ST40 is designed for use as part of the propulsion system for satellites with a mass up to 1T. It is designed to enable accurate orientation and stabilization of the spacecraft in different orbits. It provides a thrust of up to 28 mN at a maximum electric power consumption of up to 600 W, and is equipped with two heatless hollow cathodes.

A thruster unit designed for small and medium satellites (up to 500 kg). The SPS25 is able to adjust orbital parameters and ensure the maneuverability of satellites in space. The system includes one ST-25 (two hollow cathodes), a xenon feed system, and a power processing unit.

A propulsion system designed for advanced satellites constellations, enabling position correction relative to other satellites. The elements of the xenon feed system are demonstratively distributed on the surface. At the request of the customer it is possible to mount them in required volume. The propulsion system includes two ST-40 (two hollow cathodes for each thruster), the xenon feed system, and a power processing unit (PPU).

The Variable Specific Impulse Magnetoplasma Rocket (VASIMR®) engine is a new type of electric thruster in which gas (such as argon, xenon, or hydrogen) is injected into a tube surrounded by a magnet and a series of two radio wave (RF) couplers. The couplers turn cold gas into superheated plasma and the rocket’s magnetic nozzle converts the plasma thermal motion into a directed jet.

progresja-space-blink

The Applied Ion Systems AIS-VAT1-PQ Micro Vacuum Arc Thruster is designed for 1.5P PocketQubes to 1U Cubesats. It is available in both 2.5W and 5W, with a total impulse of 0.13Ns. The VAT1-PQ utilizes Solid Bismuth as a fuel allowing the lowest ignition voltage, easy triggering, and operation over a wider range of burning voltages. It weighs approximately 56 grams.

The Applied Ion Systems AIS-VAT1-DUO Dual Micro Vacuum Arc Thruster is designed for Cubesats, mainly allowing for 1U and 1/2U CubeSats. It is available in both 5W and 10W with a total impulse of 0.26Ns. The AIS-VAT1-DUO allows clients to explore the use of EP with minimal volume and power budget. It can also be utilized for ground testing for academic, student, and research purposes.

The Applied Ion Systems AIS-VAT1-QUAD Quad Micro Vacuum Arc Thruster is designed for 1U CubeSat. It utilizes Bismuth as a fuel and has a total impulse of 0.52Ns. The AIS-VAT1-QUAD allows the clients to explore the use of EP with minimal volume and power budget. The thruster weighs approximately 177 grams and it is available in both 10W and 20W.

The Applied Ion Systems AIS-SWAG1-PQ is a sublimation warm gas thruster designed for space systems. It has a total impulse of 3.2Ns with a maximum thrust of 147uN. The thruster weighs approximately 214 grams and consists of multiple inputs 12V, 5V, GND, and x1 Logic Command. It utilizes solid unpressurized Adamantane fuel with a power of 5W.

The Applied Ion Systems AIS-SWAG1-DUO-NX is a sublimation warm gas thruster designed for space systems. It weighs 430 grams and utilizes solid unpressurized Adamantane fuel. The thruster has approximately 7 hours of operating lifetime and pre-heat time of 1 hour. It also features multiple inputs 12V, 5V, GND, and x1 Logic Command.

The Applied Ion Systems AIS-SWAG1-PQ-NX - Warm Gas Thruster is a sublimation warm gas propulsion system. It uses solid unpressurized Adamantane fuel and has a power rating of 5 W. The system has a total operating lifetime of approximately 7 hours including a pre-heating time of 1 hour and ramp-up time of 3 hours to maximum thrust. It has a mass of 214g and features a variety of inputs including 12V, 5V, GND, and one Logic Command.

The Applied Ion Systems AIS-SWAG1-QUAD-NX - Warm Gas Thruster is a sublimation warm gas propulsion system. It is available with a power of 20W and weighs approximately 860 grams. The thruster consists of a variety of inputs 12V, 5V, GND, and x1 Logic Command. It has an operational lifetime capability of 7 hours and a pre-heat time of 1 hour.

The Applied Ion Systems AIS-SWAG1-QUAD is a sublimation warm gas thruster designed for space systems. It consists of a maximum thrust of 588uN and solid unpressurized Adamantane fuel with a power of 20W. The thruster weighs 860 grams and has a total impulse of 12.8Ns. It also features a variety of inputs 12V, 5V, GND, and x1 Logic Command.

The Applied Ion Systems AIS-SWAG1-DUO - Warm Gas Thruster is a sublimation warm gas propulsion system. It has a total impulse of 6.4Ns and utilizes solid unpressurized Adamantane fuel with a power of 10W. The thruster weighs approximately 430 grams and consists of multiple inputs 12V, 5V, GND, and x1 Logic Command.

The Astra Spacecraft Engine (ASE) is a Hall-effect thruster propulsion system with flight heritage. The ASE PPU provides power and control to the ASE thruster, valves, regulator, and pressure transducers. Astra provides xenon/krypton propellant feed systems. Astra has baselined a Xenon/Krypton PSMA with a single string bang-bang regulator with orifice flow split for cathode, anode, and ignition flow.

The Astra Spacecraft Engine (ASE) Max is a kilowatt-class propulsion system using krypton or xenon propellant. The thruster is suitable for missions requiring high total impulse per thruster. ASE Max is ideal for communication satellite constellations, for small GEO spacecraft, and as an enabling technology for high throughput LEO, GTO-GEO transfer, and cislunar missions. ASE Max includes a magnetically shielded thruster which is tuned to optimize performance with krypton propellant.

The Advanced Technology Institute (ATI) Nano Pulsed Plasma Thruster System (nanoPPT) for Micro-Satellites is a pulsed plasma thruster using PTFE. It is designed to provide competitive delta-V and 3-axis attitude control to CubeSats and microsats.

The ALIENA MUSIC Electric Propulsion System - Hot Mode is designed for microsatellites. It consists of hollow cathode technology that allows high thrust/high specific impulse operation at 100 W in hot mode. The system weighs approximately 5 kg and has a configurable total impulse of 15 kNs.

The ALIENA MUSIC Electric Propulsion System - Self-ignition mode is designed for nanosatellites. It consumes less than 20W of power and weighs approximately 2 kg. The system has a total impulse of 150 Ns and it is configurable.

The ALIENA MUSIC Electric Propulsion System - Dual Mode/Fault-tolerant is designed for microsatellites. It integrates both self-ignition technology and hollow cathode technology. The system has a wide thrust range and a fault-tolerant system that can ignite on demand. It weighs approximately 5 kg and has a configurable total impulse of 15 kNs.

The Airbus PureLine Topaz/THORs is an electronic propulsion subsystem solution for satellites operating in the LEO. It is based on low power hall effect thruster (HET) technology and is well suited for orbit raising, station keeping and deorbiting maneuvers. It also has a bi-compatibility to the latest generation plasma thrusters. The product weighs 10 kgs and has a total impulse per string up to 260kN.

Powerful Thruster is suitable for installation on heavy spacecraft. Ideal for GEO satellites. A reasonable choice for tasks such as orbital keeping, in-orbit maneuvers, disposal orbiting.

Electric propulsion system based on 100W hall thruster units. The system's full power level was 250W, dry mass of 17kg. With 10kg of propellant (Xenon) the system was capable to deliver about 90kN*s of total impulse.

Sufficiently high specific characteristics for this class of thrusters allow efficient use of onboard resources. Two coils configuration was used for the thruster design, large variety of operational modes options were achieved due to well designed magnetic field configuration.

The low power thruster is ideal for small spacecraft. Sufficiently high specific characteristics for this class of thrusters allow efficient use of onboard resources. This engine will be the optimal choice for spacecraft from 6U.

The Benchmark Space Systems Starling is a cold gas propulsion system with a specific impulse of 70s-140s. The propellant options include traditional pressurant gas or Benchmark's patented ODPS™ gas generation technique. Starling can be configured with 1-4 thrusters. It is often used for momentum management and attitude control and can be scaled down for primary CubeSat operations. It is available with the option of a resistojet thruster configuration.

The Benchmark Space Systems XANTUS is a metal plasma thruster system that is designed for small satellites. Xantus is a milli-Newton class Electric Propulsion System of Benchmark Space Systems. Xantus does not use gas or liquid propellants, neutralizers, heaters, or high-voltage electronics. It is designed to have the highest total impulse for its size. The thruster was developed by Alameda Applied Sciences Corporation and had the support of NASA in designing and developing the system.


Thanks for reading! If you would like any further help identifying a CubeSat thruster for your specific needs, please file a request on our platform and we’ll use our global network of suppliers to find an option.

Have you noticed that your company isn’t included in this article? Simply send us an email today, and we’d be happy to work with you to showcase your products to the satsearch community!
